Stop renewing a vendor whose differentiating features the enterprise already owns.

What was on fire

Nothing was down. The invoice was the fire: close to $700k a year in Alation licensing for roughly 1,300 users, and an enterprise vendor search already running to replace it — with another vendor. It just doesn’t make a whole lot of sense to keep spending seven hundred thousand dollars a year for the users we have. The features that justified the price were already owned: Collibra held the business metadata, other in-house systems covered the rest. The enterprise was paying twice for capability and once for a query editor.

$700,000 a year in Alation licensing ÷ 1,300 users on it $540 a seat, a year Both figures as reported: close to $700k a year, roughly 1,300 users. What the seat bought A query editor. Collibra already held the business metadata; other in-house systems covered the rest.
Fig. 01 — Arithmetic, not an invoice. Close to $700,000 a year across roughly 1,300 users is about $540 a seat, and what the seat bought was a query editor.

Fig. 01 · pinch or scroll to zoom · drag to pan

Constraint set

No feature-parity option existed. DBeaver doesn’t do most of what Alation does, and rebuilding all of it was never on the table — the swap only worked because those features were already duplicated in tools the enterprise owned. The business didn’t really care. The databases declare almost no foreign keys, so any join help had to be mined, not read. And roughly 1,300 users had to move without a stop-the-world cutover.

System diagram

Fig. 02 — One VPC. The fork and Temporal scale horizontally on Fargate; Aurora holds the mined metadata; results leave by S3 or email.

Fig. 02 · pinch or scroll to zoom · drag to pan

Architecture decisions

  1. Fork open-source DBeaver instead of buying the next vendor. The search was already headed toward a like-for-like replacement. Rejected it, because the differentiating features were already owned elsewhere — the seat being paid for was, in practice, a query editor. DBeaver’s Apache 2 license made the fork legal and clean.
  2. engraving of a tree trunk showing a graft union bound in a splint and knotted rope, one stub branch tied off at the left, gnarled roots exposed at the base, the scion side above right carrying leafy branches with apples
    A hard fork, not plugins. The changes went too deep for the extension surface. The cost is accepted with eyes open: nothing goes back upstream, and the fork is maintained in-house from now on.
  3. Wire in the metadata the enterprise already owned rather than rebuild a catalog. Collibra’s business metadata streams into IntelliSense — as the completion list appears, the developer sees in real time what each column means. Rejected: replicating Alation’s catalog inside the new tool.
  4. Mine joins instead of trusting the schema. With no declared foreign keys, scanned every stored procedure and view, extracted the join predicates into their own table, and surfaced them whenever a user writes a join.

Not again: don’t keep renewing a vendor whose differentiating features the enterprise already owns.

Recovery / operate path

Two to three months from vendor comparison to production. Scheduled queries run on Temporal — write a query in the tool, schedule it for seven in the morning, results go out by email or land in S3. Everyone gets schema-level read access by default — every database, every table, every column visible; touching data requires your own credentials. Alation is sunsetting over the coming months, and the licensing spend goes with it when the contract ends. No adoption metric published.

What changed after

The query tool is owned in-house now — a fork with no route back to upstream, maintained by the enterprise that runs it. That trade was made knowingly. The renewal conversation is over.

Anonymization notes

The client ships by name; the people do not. No internal org names, no team names. The vendors are the story and stay named: Alation out, DBeaver forked. User count rounded; the licensing figure is as it was reported internally. Stack footnote: DBeaver (Apache 2), Collibra, Temporal, ECS Fargate, Aurora Serverless v2, ALB with ACM, Amazon S3.

Who this is for

  • An enterprise paying six figures a year for a tool whose best features are duplicated in systems it already owns.
  • Databases with no declared foreign keys, and analysts who need to know how tables actually join.
  • A metadata catalog full of business context that never reaches the people writing SQL.
